Lifting Chain Suppliers

Lifting Chain Suppliers

Lifting chains are often used in conjunction with other types of lifting equipment, such as cranes, hoists, or winches. They are attached to the object that needs to be lifted using a hook or other type of fastener, and they are used to lift and move the object by pulling on the chain. The speed at which the object is lifted or moved can be controlled by adjusting the hand crank or lever on the lifting equipment, and the position of the object can be adjusted by moving the lifting chain to a different location.

Get A Quote

Business philosophy

<p>The company has always adhered to the "quality" for survival, reputation, as the leading business philosophy, has an excellent team of engineers, perfect production equipment and after-sales service.</p>

After sales service and technical assistance

<p>After-sale service and technical assistance: company provides after sales service and technical assistance as per customers' requirement and needs with response within 24 hours.</p>

Personalized service

<p>Quality assurance,reaasonable prices, service country of origin, experience technical staff, excellent product performance.</p>

Stock

<p>There are emergency stocks for regular size perennially.This to save time for you.</p>

about us

We Have The Best Solutions for Your Business

Shandong Lisheng Machinery Co., Ltd. is a new generation enterprise dedicated to the hardware industry. It is located in Jining City, Shandong Province, the hometown of Confucius and Mencius. The company is a professional hardware supporting enterprise integrating design, research and development, production and sales. The main products are chains, wire ropes and their accessories: shackles, turn buckles, clips, rings, snap hooks and other forgings and castings, and accept drawings and samples for processing.

Learn More

Working Load Limit (WLL) of Chain

The safety measure was identifying which types of chain are appropriate and strong enough for overhead lifting. Anytime we move or lift a load it is dangerous. Moving a load along the ground has the advantage that the ground is supporting the load. We have to overcome the coefficient of friction to move the load. The chain’s working load limit does not have to match the weight of the load. It needs to be able to handle the tension applied, which is based on the surface that it is being moved over plus some fraction of the weight of the load. This can be calculated using formulas.

If we lift that same load off the ground, we now have to overcome gravity. The chain’s working load limit will have to be of sufficient strength to support the weight of the load plus any additional forces imposed by angles and hitch type(s) used.

About Chain Grades

One of the safety measures implemented was to place chain in Grades based on the ultimate breaking strength of that chain. This number is what we see today G30, G43, G70, G80 & G100 and the common chain grades. The number after each letter is N/mm2. For example, G80 means that the maximum stress on the chain at ultimate strength is 800 newtons per millimeter squared.

Application Fields of Lifting Chains

Lifting chains find application in a wide range of industries and sectors that involve material handling and lifting operations. They are commonly used in construction sites for lifting heavy equipment, building materials, and structural components. Lifting chains are valuable in manufacturing facilities for hoisting machinery, engines, or heavy parts. They are also employed in the transportation and logistics industry for cargo handling and securing loads on trucks, cranes, or ships. Additionally, lifting chains are used in the mining, oil and gas, and marine sectors for various lifting and rigging tasks.

Characteristics of Lifting Chains

Lifting chains are typically made from high-quality alloy steel, which provides excellent strength and durability. They consist of a series of interconnected links that form a continuous chain. Lifting chains are available in different sizes, grades, and configurations to match specific load requirements. They may feature different types of end fittings, such as hooks, shackles, or rings, for convenient connection to lifting devices. Lifting chains are designed to meet industry standards and regulations for load capacity, safety, and performance.

User Reviews

What users say about Us

I am very satisfied for top quality product,quick response and attention provided by this seller and company,Thank you!

Christopher Anderson

Quikly send,very good communication,all is ok,without problem.

Ashley Thomas

Very good quality,fast and safe shipment,Nothing to improve

Daniel Jackson

Great seller!Always online and helpful.Speedy delivery,very good and secure packing.

Jennifer White
Frequently Asked Question

Do you have any question?

Only alloy steel chain, grade 80 or 100 is to be used for overhead lifting. Alloy steel chain will stretch when over loaded; other types of steel may break without warning. Steel chains slings used for lifting are manufactured specifically for lifting.

The most common reason for damage to chain and chain links stems from improper use, e.g. not complying with the chain's WLL chart. Using a chain incorrectly can cause damage such as cracks, breaks, stretched links or fittings, excessive wear, nicks, gouges and rigid chain links or fittings

Equipment should generally be inspected every three months, or more frequently if subjected to severe conditions.

Our updates and blog posts

Basic knowledge of wire rope

The steel wire rope has high strength, light weight, stable operation, not easy to break suddenly and reliable operation.

Advantages and application analysis of galvanized iron chain

With the development of today's society, the types of chain products are also constantly innovating. The use of chains should be widely used in many industries.

Types of anchor chains

Anchor chain refers to a special chain that connects the anchor and the hull and transmits the anchor's grip.
